360W 6 Channels Mixing Amplifier With MP3 FM Bluetooth Players OEM ODM

Model Number:	PA-360ZM
MOQ:	100

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Warranty:

3years

Dimension:

485*340*88

>=70DB

Output Power:

Radio Function:

Operating Voltage:

70V/100V

Shape:

Rectangle

Frequency Response:

80-16KHz+/-3DB

Recommended Use:

For Televisions, For Music Players

Highlight:

360W 6 Zones Mixing Amplifier

6 Zones Mixing Amplifier

MP3 And Bluetooth Mixer Amplifier

Product Description

High Power 360W 6 Zones with MP3 and Bluetooth Players Mixing Amplifier with FM

Product Overview

PA-60ZM-PA-1000ZM series professional mixing amplifiers feature 6 zones with MP3 and Bluetooth players for versatile audio distribution.

Key Features

Advanced power amplification circuit with 2 MIC inputs, 3 line inputs, and 1 AUX output
Supports 4-16Ω low impedance output and 70V/100V output options
Individual volume control with adjustable treble and bass for each channel
Built-in MP3 player and FM radio operated by remote control
Bluetooth connectivity for wireless music streaming from mobile devices
Priority system: MIC1 and fire alarm override other signals when activated
Comprehensive status indicators for signal, peak value, and protection
Built-in limiter protects speakers from signal overload
6-zone output with individual volume control for each zone
3-channel fire alarm function with automatic or manual activation
Supports short circuit alarm activation with multiple voltage options (0V, 3.3V, 5V, 12V, 24V)
8MB memory card for firmware updates and content storage

Technical Specifications

Model	PA-60ZM	PA-120ZM	PA-240ZM	PA-360ZM	PA-560ZM	PA-650ZM	PA-1000ZM
Rated Power	60W	120W	240W	360W	560W	650W	1000W
Input Voltage	AC220V/50HZ
AUX Sensitivity	-6DB
MIC Sensitivity	-40DB
Frequency Response	80HZ-16KHZ+/-3DB
THD	≤0.1%
SNR	≥70DB
Line Output	0DB
Protection Circuit	DC, Overload, AC fuse, Short-circuit
Operating Temperature	-5℃ to 80℃
Operating Humidity	20℃-80℃ relative humidity

360W 6 Channels Mixing Amplifier With MP3 FM Bluetooth Players OEM ODM 0

360W 6 Channels Mixing Amplifier With MP3 FM Bluetooth Players OEM ODM 1

360W 6 Channels Mixing Amplifier With MP3 FM Bluetooth Players OEM ODM 2

360W 6 Channels Mixing Amplifier With MP3 FM Bluetooth Players OEM ODM 3

360W 6 Channels Mixing Amplifier With MP3 FM Bluetooth Players OEM ODM 4

360W 6 Channels Mixing Amplifier With MP3 FM Bluetooth Players OEM ODM 5
